Boat (Small Craft <24m) Electrical Systems Design and Compliance Aid
Wiring Pilot is an innovative new system to enable designers of electrical systems for Small Craft (<24m) to assess likely* compliance with major national and international standards - both current and under development.
Wiring Pilot is designed to provide information which can be used to confirm compliance with selected standards with a Notified Body or other surveyor.
Wiring Pilot covers requirements for compliance with Small Craft standards and Codes of Practice for Electrical Systems on Small Craft for
- EU (RCD) / UK (RCR)
- US (ABYC)
- IMO/IEC (Small Vessels Only)
- Australia/New Zealand
- Canada
- Hong Kong .. and more to come
Wiring Pilot offers the ability to check compliance for a single system design with multiple standards from different authorities.
Wiring Pilot keeps all of your Small Craft Electrical Projects in one place
NOT online - all data is local to your computer and never uploaded from your system. Confidentiality guaranteed - we have no possible access to your data. This is critical as your electrical design is your intellectual property not ours.
NOT AI. This is critical as AI driven software, by its very nature, attempts to answer every question for you, which can lead to entirely logical conclusions derived from published standards which are erroneous. Using an AI online means your designs can be incorporated in other designer's work with no royalty.
Knowing how to interpret a standard is critical. The team behind Wiring Pilot is actively involved in developing Small Craft standards and is involved with revisions of the main ISO standards so we are always aware of what is coming.
Circuit design from Origins of Power, to Nodes (Distributors/Combiners) to Consumer
Supports systems at common DC voltages (12, 24, 48V) and AC voltages (120/230/240/400/690V) used in Europe, the US and in other countries around the world.
Wiring Pilot includes or will include:
Cable Schedule
OCPD Schedule
Circuit List with lengths, overcurrent and fault protection requirements.
Adaptation to different fault protection requirements for IT/TNS wired circuits
Automatic voltage drop calculations
Automatic cable derating for bundling and engine spaces
Automatic re-calculation according to insulation temperature ratings
Automatic Wiring Schematic Block diagram creation - output as PDF or SVG
Creates imports for (certain) Notified Body assessment software
Generation of automatic circuit labels created using a hierarchical numbering system which clearly identifies each cable and its voltage.
Ensures OCPD selectivity
Automatic OCPD sizing according to consumer node power requirements and cable current carrying capabilities
Wiring Pilot will be initially offered for the Windows platform. Mac and Linux to follow.
Due to the complexity of the information required to define a standards compliant circuit it is not possible to offer a smart phone version - there is simply no space on the screen. Versions for Android/IOS tablets may be possible in the future but currently there is no plan for this.
This is a professional design aid and includes many advanced concepts. Outputs may or may not provide compliance with applicable laws and standards. Wiring Pilot, if used without significant electrical systems knowledge, may produce erroneous results and unless you are an experienced electrical system designer we urge you to have any outputs confirmed by a qualified person before use.
* Wiring Pilot does not in itself prove compliance with any published standard, Code of Practice, survey or insurance requirement. Wiring Pilot is NOT approved by any National or International Authority and is NOT a replacement of owning, using and understanding the required standards. Installed electrical systems should be checked and surveyed for safe operation and conformity to design.
